BEHRINGER CONTROL2USB High-End Studio Control and Communication Center

€119.00

High-End Studio Control and Communication Center with VCA Control and USB Audio Interface

Αποστολή σε 1-3 ημέρες

Όταν έρθει η ώρα να ασχοληθείτε με την ηχογράφηση ή τη μίξη, το τελευταίο πράγμα που θα θέλετε να κάνετε είναι να συρθείτε κάτω από το γραφείο σας και να συνδέσετε καλώδια. Το εξαιρετικά εύχρηστο CONTROL2USB σας απογειώνει, τοποθετώντας το Master Volume, το Talkback, την επιλογή πηγής και τον έλεγχο των monitor στα χέρια σας. Τώρα μπορείτε να επιλέξετε από έως και 3 σετ ενεργών στούντιο monitor και 4 διαφορετικές πηγές στερεοφωνικής εισόδου για να δημιουργήσετε ισχυρές, προσαρμοσμένες μίξεις . Επιπλέον, το ενσωματωμένο μικρόφωνο Talkback σάς επιτρέπει να επικοινωνείτε απευθείας με όποιον ηχογραφεί. Το απίστευτα ευέλικτο CONTROL2USB σας κάνει τον master του studio σας!

Product Features

Premium, ultra-low noise and high headroom studio control and communication center
All-in-one Master Volume controller, Source selector, Monitor switcher and Talkback box
4 stereo inputs with independent level controls plus additional Monitor Mix input for your DAW
3 independent and adjustable Monitor outputs to connect up to 3 sets of studio monitors
Built-in Talkback microphone with Level control for direct communication with musicians
Large Volume knob with true VCA control for extremely precise level adjustments
Built-in stereo USB Audio Interface, perfect for computer-based studios
Premium-quality phono preamp for direct turntable connection
2 200 Ω balanced / 100 Ω unbalancedpowerful headphone amplifiers with separate volume controls
Convenient Mono, Mute and Dim functions right at your fingertips
High-precision dual 12-segment LED meters with input/output source switch
“Planet Earth” switching power supply for maximum flexibility (100 – 240 V~), noise-free audio, superior transient response plus low power consumption for energy savings

Specifications :

Frequency Response
Line-level inputs and outputs
1/4″ jack, balanced or unbalanced	10 Hz to 40 kHz (+0 dB / -1 dB)
Phono input	20 Hz to 20 kHz (±1 dB)
Distortion (THD & IMD)
Line-level inputs to line-level outputs (unity gain)	<0.02 %, 20 Hz to 20 kHz @ +4 dBu
Phono input	<0.10 %, 20 Hz to 20 kHz @ +4 dBu
Noise Floor
Unity gain with Input 1, 2 and 3 assigned	-86 dBu, 20 Hz to 20 kHz
Monitor A, B and C outputs, studio output, DAW, 2-track A & B outputs	-90 dBu, 20 Hz to 20 kHz
Phono input	-75 dBu, 20 Hz to 20 kHz
Equivalent input noise (E.I.N.)	-119 dBu, 20 Hz to 20 kHz
Dynamic Range
Line inputs	107 dB
Phono input	88 dB
Crosstalk
Adjacent inputs	95 dB @ 1 kHz
Left to right / right to left	85 dB @ 1 kHz
Muted / level of	95 dB @ 1 kHz
Control Range
Input level	±10 dB
Output level	-12 dB to 0 dB
Dim switch	0 dB / -20 dB
Rated Input Voltage
Line inputs (+4 dB level setting)	+4 dBu / +30 dBu (nominal / maximum)
Line inputs (-10 dB level setting)	-10 dBu / +15 dBu (nominal / maximum)
Phono input @ 1 kHz, nominal gain	5 mV / 90 mV (nominal / maximum)
Rated Output Voltage
All line-level outputs (+4 dB level setting)	+4 dBu / +21 dBu (nominal / maximum)
All line-level outputs (-10 dB level setting)	-10 dBu / +8 dBu (nominal / maximum)
Maximum Voltage Gain
Input 1, 2 and 3 to:
Monitor A, B and C outputs	+32 dB
DAW, 2-track A & B, and phones (rear) outputs	+22 dB
Studio output	32 dB
Phones 1 & 2 outputs	32 dB (output loaded @ 100 kΩ)
Monitor mix input to:
Phones (rear) outputs	12 dB
Studio output	22 dB
Phones 1 & 2 outputs	22 dB (output loaded @ 100 kΩ)
Phono input @ 1 kHz to:
Monitor A, B and C outputs	65 dB
DAW, 2-track A & B, and phones (rear) outputs	55 dB
Studio output	66 dB
Phones 1 & 2 outputs	66 dB (output loaded @ 100 kΩ)
Input Impedance
Line input	20 kΩ balanced / 14 kΩ unbalanced
Phono input	40 kΩ
Output Impedance
Line output	200 Ω balanced / 100 Ω unbalanced
Input/Output VU Meters
12-segment LED	CLIP, +10, +7, +4, +2, 0, -2, -4, -7, -10, -20, -30 dB
Talkback Section
Automatic gain control (AGC)	Yes
Nominal output level	+4 dBu (+4 dB output level setting)
Output level range	-? to +10 dB
Power Supply / Voltage (Fuses)
Mains voltage	100-240 V~, 50/60 Hz
Fuse	T 1AH 250 V
Power consumption	15 W
Mains connection	Standard IEC receptacle
USB
Audio	Stereo in / out
Connector	Type B
Sample rate	44.1 / 48 kHz
Dimensions/Weight
Dimensions (H x W x D)	87 x 389 x 198 mm (3.4 x 15.3 x 7.8″)
Weight	2.4 kg (5.3 lbs)
